G / G2
140 mm - 3040 mm
± 5 µm y ± 3 µm
1 Vpp
0,1 μm
G2P / G2OP
TTL
1 μm
G2X / G2OX
TTL
0,5 μm
G2Y / G2OY
TTL
0,1 μm
G2W / G2OW
TTL
0,05 μm
G2Z / G2OZ
光栅尺型号 有O: 距离编码 X：TTL差动方波 P：1Vpp正弦波
无O：增量Io（Z） 每50mm一个 -5：精度±5um -3：精度等级±3um
| GX-140-5 | GOX-140-5 | GP-140-5 | GOP-140-5 |
| GX-240-5 | GOX-240-5 | GP-240-5 | GOP-240-5 |
| GX-340-5 | GOX-340-5 | GP-340-5 | GOP-340-5 |
| GX-440-5 | GOX-440-5 | GP-440-5 | GOP-440-5 |
| GX-540-5 | GOX-540-5 | GP-540-5 | GOP-540-5 |
| GX-640-5 | GOX-640-5 | GP-640-5 | GOP-640-5 |
| GX-740-5 | GOX-740-5 | GP-740-5 | GOP-740-5 |
| GX-840-5 | GOX-840-5 | GP-840-5 | GOP-840-5 |
| GX-940-5 | GOX-940-5 | GP-940-5 | GOP-940-5 |
| GX-1040-5 | GOX-1040-5 | GP-1040-5 | GOP-1040-5 |
| GX-1140-5 | GOX-1140-5 | GP-1140-5 | GOP-1140-5 |
| GX-1240-5 | GOX-1240-5 | GP-1240-5 | GOP-1240-5 |
| GX-1340-5 | GOX-1340-5 | GP-1340-5 | GOP-1340-5 |
| GX-1440-5 | GOX-1440-5 | GP-1440-5 | GOP-1440-5 |
| GX-1540-5 | GOX-1540-5 | GP-1540-5 | GOP-1540-5 |
| GX-1640-5 | GOX-1640-5 | GP-1640-5 | GOP-1640-5 |
| GX-1740-5 | GOX-1740-5 | GP-1740-5 | GOP-1740-5 |
| GX-1840-5 | GOX-1840-5 | GP-1840-5 | GOP-1840-5 |
| GX-1940-5 | GOX-1940-5 | GP-1940-5 | GOP-1940-5 |
| GX-2040-5 | GOX-2040-5 | GP-2040-5 | GOP-2040-5 |
| GX-2240-5 | GOX-2240-5 | GP-2240-5 | GOP-2240-5 |
| GX-2440-5 | GOX-2440-5 | GP-2440-5 | GOP-2440-5 |
| GX-2640-5 | GOX-2640-5 | GP-2640-5 | GOP-2640-5 |
| GX-2840-5 | GOX-2840-5 | GP-2840-5 | GOP-2840-5 |
| GX-3040-5 | GOX-3040-5 | GP-3040-5 | GOP-3040-5 |
| GX-140-3 | GOX-140-3 | GP-140-3 | GOP-140-3 |
| GX-240-3 | GOX-240-3 | GP-240-3 | GOP-240-3 |
| GX-340-3 | GOX-340-3 | GP-340-3 | GOP-340-3 |
| GX-440-3 | GOX-440-3 | GP-440-3 | GOP-440-3 |
| GX-340-3 | GOX-340-3 | GP-340-3 | GOP-340-3 |
| GX-640-3 | GOX-640-3 | GP-640-3 | GOP-640-3 |
| GX-740-3 | GOX-740-3 | GP-740-3 | GOP-740-3 |
| GX-840-3 | GOX-840-3 | GP-840-3 | GOP-840-3 |
| GX-940-3 | GOX-940-3 | GP-940-3 | GOP-940-3 |
| GX-1040-3 | GOX-1040-3 | GP-1040-3 | GOP-1040-3 |
| GX-1140-3 | GOX-1140-3 | GP-1140-3 | GOP-1140-3 |
| GX-1240-3 | GOX-1240-3 | GP-1240-3 | GOP-1240-3 |
| GX-1340-3 | GOX-1340-3 | GP-1340-3 | GOP-1340-3 |
| GX-1440-3 | GOX-1440-3 | GP-1440-3 | GOP-1440-3 |
| GX-1540-3 | GOX-1540-3 | GP-1540-3 | GOP-1540-3 |
| GX-1640-3 | GOX-1640-3 | GP-1640-3 | GOP-1640-3 |
| GX-1740-3 | GOX-1740-3 | GP-1740-3 | GOP-1740-3 |
| GX-1840-3 | GOX-1840-3 | GP-1840-3 | GOP-1840-3 |
| GX-1940-3 | GOX-1940-3 | GP-1940-3 | GOP-1940-3 |
| GX-2040-3 | GOX-2040-3 | GP-2040-3 | GOP-2040-3 |
| GX-2240-3 | GOX-2240-3 | GP-2240-3 | GOP-2240-3 |
| GX-2440-3 | GOX-2440-3 | GP-2440-3 | GOP-2440-3 |
| GX-2640-3 | GOX-2640-3 | GP-2640-3 | GOP-2640-3 |
| GX-2840-3 | GOX-2840-3 | GP-2840-3 | GOP-2840-3 |
| GX-3040-3 | GOX-3040-3 | GP-3040-3 | GOP-3040-3 |
